Description
A torque multiplier with adaptor for removing and retightening the tight pulley securing bolt found on listed Ford engines.
It is suitable for 1.0 EcoBoost, 1.0 Duratec, 1.1 Duratec, 2.0 Duratorq-TDCi and 2.0 EcoBlue Diesel engines.
The 5:1 torque ratio matches the OEM specification.
The tool has a 1/2" drive female input and 3/4" drive male output.
Maximum input torque is 300Nm and maximum output torque is 1500Nm.
Includes sockets for the listed applications.
Key Features:
- Torque multiplier with Ford EcoBoost and EcoBlue adaptor
- For removing and retightening tight pulley securing bolts
- Suitable for listed Ford 1.0, 1.1 and 2.0 engines
- 5:1 torque ratio matches OEM specification
- 1/2" drive female to 3/4" drive male
- Maximum output torque: 1500Nm
OEM References:
- 303-1611, 303-1611-01, 303-1611-02
Applications:
- Ford B-Max 2012-2018
- Ford C-Max 2012-2018
- Ford Grand C-Max 2017-2018
- Ford EcoSport 2015-2019
- Ford Fiesta 2012-2019
- Ford Focus 2012-2018
- Ford Mondeo 2015-2018
- Ford Transit Courier 2014-2020
- Ford Transit Connect 2013-2018
- Ford Grand Tourneo Connect 2013-2018
- Ford Tourneo Courier 2014-2020
Engine Codes:
- M1DA, M1DD, M1JA, M1JC, M1JE, M1JH, M1JJ, M1CA, M1CB, M2DA, M2DB, M2DC, M2GA, M2GB
- P4JA, P4JB, P4JC, P4JD, SFCA, SFCB, SFCC, SFCD, SFDB, SFJA, SFJB, SFJC, SFJD
- XMJA, XMJB, XMJC, XMJD, YYJA, YYJB
Specifications:
- Input drive: 1/2" female
- Output drive: 3/4" male
- Torque ratio: 5:1
- Maximum input torque: 300Nm
- Maximum output torque: 1500Nm
- Includes sockets: Yes
